EzoPrint adds depth and texture to any wall, improves acoustical comfort in any space, brings practicality and style to any architectural work.

You can transform your environment with prints of favorite building materials, abstract designs or your own brand.

Add visual interest to any wall, while providing acoustic absorption, tackability and modern style. With design options ranging from materials that imitate architectural choices to more abstract or branded options, you can transform your environment.

Key Features

Branding & custom print

Do you want to make your brand more prominent in your professional environment while improving acoustics? Do you want to bring in some artwork that also absorbs sound? Or do you want to take one of our patterns and change the colors up? We also do custom prints – photographs, illustrations, artwork or logos and brand imagery.

Customizable Parameters

Geometric Properties
Tile dimensions

Material Thickness:
3/8″ (9mm) or 1/2″ (12mm)

Applicable File Formats:
Illustrator , Photoshop. In Design CC or below  (.ai, .eps, .psd, .psb, .tif, .eps, (high res) .jpg, .indd and .idml)

MODELS

Brick & Stone

Brick walls have long been a design choice to add character to your indoor space – now you can combine that with sound absorption.

Wood

Wood grain can bring warmth to any room. Using imagery of knotty wood, particle board, or pristine hardwood, can bring texture into any area.

Sound Absorption Performance

Sound absorption performance depends on mounting/installation conditions, material thickness, pattern & style.

½” (12mm)
D50
½” (12mm)
Direct
3/8” (9mm)
D50
3/8” (9mm)
Direct

documentation

f
Specifications
Print specs
1
Dimensions
downloads
Customizable parameters

Specifications

COMPOSITION

100% pet (min. 50% recycled content)

FEATURES

  • Available in 30 standard color combinations.
  • Easy and unobtrusive mounting
  • Fully tackable surface

 ACOUSTICS
Superior sound absorption characteristics
(NRC: 0.75, SAA: 0.58, ASTM C423, 9mm)
(NRC: 0.80, SAA: 0.80, ASTM C423, 12mm)

FIRE TESTING

North America:

  • ASTM E-84 Class A
  • CAN/ULC S102-10

 Europe and UK:
EN13501-1: 2007

Print Specifications



  • Water or latex based printing
  • Little to no film thickness with 1-3 picolitre droplets
  • No effect on acoustical performance
  • Color Space: CMYK
  • 600-1200 dpi print resolution
  • Compliance: REACH, PVC Free, Nickel Free, FSC, UL Green Gold,  Eco Mark Certification Number 141420017, UL ECOLOGO, AgBB Citeria, ASTM F793 Type II

Dimensions

EZO PRINT
   WIDTH      HEIGHT     THICKNESS
21″ (533mm) 21″ (533mm) 3/8″ (9mm) 1/2″ (12mm)
42″ (1067mm) 42″ (1067mm) 3/8″ (9mm) 1/2″ (12mm)
42″ (1067mm) 90″ (2286mm) 3/8″ (9mm) 1/2″ (12mm)

Please note that all dimensions are nominal, supplier reserves the right to adjust sizing without prior notification.

This is a portion of the complete set of dimensions, to get the full list, please download Ezo Print Brochure.

To get the complete set of dimensions please download Ezo Print Brochure.

INSTALLATION INSTRUCTIONS

Icon

ezo Tape Installation 570.60 KB 285 downloads

...

Customizable Parameters



  • Geometric Properties: Length, width and layer quantity
  • Material Thickness: 3/8″ (9mm) or 1/2″ (12mm) sheets can be layered to form a specific thickness
  • Color: Each layer can be printed with a different pattern
  • Pattern and Cut: Custom patterns and cut shapes are available
  • Digital Print: Custom graphics and textures can be printed

Contact our design team for custom applications.
